Aluminium Compression Cable Lugs Manufacturer, Supplier & Exporter

Leading Manufacturer of Aluminium Compression Cable Lugs, High Quality Aluminium Compression Cable Lugs Exporter in Mumbai, India

Aluminium Aluminium Compression Cable Lugs Manufacturer in India.

Multimet Overseas is the most trusted and leading manufacturer, supplier and exporter of Aluminium Compression Cable Lugs. Specifications and processing of aluminium compression cable lugs are the same as those for pure aluminium versions. Like aluminium cable lugs conforming to DIN 46239, aluminium compression cable lugs feature a barrier design allowing the use of oil soaked and paper insulated cables which prevents oil leakage.

Aluminium cable lugs are suitable for connecting LV and MV aluminium cables, 11kV-33kV. The internal surface of the cable lug is protected against oxidation with the inclusion of specific grease with an exceptionally high dropping point – the solid construction cable lugs are water-blocked without inspection holes and suitable for both indoor and outdoor applications on switchgear, transformer or pole-mounted installations Aluminum Tubular Power Cable Lug Long Barrel Compression Type Standard DIN 1712/1976Teil 3, Copper lugs crimping type, copper lugs soldering type.

Our high-quality Aluminium Compression Cable Lugs are well recognized by our worldwide customers. If you looking to buy these Aluminium Compression Cable Lugs. Contact us today with your requirement for the best prices.

Solid Copper Earth Rod Specifications:

CABLE SIZE mm2	Ø E	DIM IN mm (A)	DIM IN mm (C)	DIM IN mm (D)	DIM IN mm (P)	DIM IN mm (B)	DIM IN mm (L)	PER BOX
16	8.2	5.5	11	20	21	41	69	150
16	10.5	5.5	11	20	21	41	69	150
25	8.2	6.5	15	22	21	41	69	75
25	10.5	6.5	15	22	21	41	69	75
35	10.5	8	15	25	22	50	79	75
35	13	8	15	25	22	50	79	75
50	10.5	9.7	18	26	24	50	81	45
50	13	9.7	18	26	24	50	81	45
70	10.5	11	18	26	26	62	95	40
70	13	11	18	26	26	62	95	40
95	10.5	13.1	20	29	28	73	109	35
	13
	17
120	13	14.7	22	32	30	73	114	20
120	17	14.7	22	32	30	73	114	20
150	13	16.5	25	36	34	83	128	10
	17
	21
185	13	18.1	28	45	36	83	131	5
	17
	21
240	13	21	28	45	44	86	144	5
	17
	21
300	17	23.2	34	55	54	89	157	5
300	21	23.2	34	55	54	89	157	5
400	17	26	38	55	60	113	187	5
400	21	26	38	55	60	113	187	5
500	17	29	45	65	64	125	205	2
500	21	29	45	65	64	125	205	2
630	17	33.5	45	65	68	140	225	2
630	21	33.5	45	65	68	140	225	2
800	21	37.6	58	84	78	147	250	2
800	27	37.6	58	84	78	147	250	2
1000	21	41.5	60	87	90	160	280	2
1000	27	41.5	60	87	90	160	280	2
